JINKO JK7110+ Programmable Withstand Voltage Insulation Tester (0～5kV(AC)±（2%+5V))

Output Voltage: 0 ~ 5kV (AC) ± (2% + 5V)

Upper Limit of AC Current: 0.10 ~ 12.00mA ± (2% + 2 digits)

Lower Limit of AC Current: 0.00 ~ 20.00mA ± (2% + 2 digits)

LCD: 16 x 2 LCD

Test Time: 0.1 ~ 999.9s ± (2% + 0.05 sec) at 5V

Remote Control:

Input: Test, Reset

Output: Pass, Fail, Test-in-Process

Test Alarm: Buzzer, Light

Correction Methods: Software Calibration

Memory Device: Can remember the voltage, current, resistance, and time settings

Temperature/Humidity: 0°C ~ 40°C, ≤ 75% RH

Standard Attachment: 26002A

Datasheet

Manual

Characteristics:

Microcomputer digital design - production, operation is simple and safe to use

Maximum current: 20mA, AC - DC maximum current: 10mA

Voltage slow rise, in line with domestic and international safety standard requirements

Various test results - intuitive and accurate

Built PLC remote control interface

Keyboard lock and memory lock function

Automatic conversion between voltage and grounding insulation test modes

Adjustable time-voltage gradient for breakdown point detection

Lower limit resistance in current

Arc detection function (1-9 levels)

15 test memory models

RS232C interface and PLC interface available
