JINKO JK2683B Fast Insulation Tester (0Ω to 4000MΩ)

Test range: 0Ω to 4000MΩ (5 ranges)

Basic accuracy: ±2% rdg. ±5 dgt.

25 V ≦ V < 100 V [0～20 MΩ]

100 V ≦ V < 500 V [0～20 MΩ]

500 V ≦ V ≦ 1000 V [0～200 MΩ]

Test voltage: 25~1000V DC 1.8mA

Test speed: 50ms (fast) / 500ms (slow)

Connection exception display:

High pressure end opening: "ContHi"

Low pressure end opening: "ContLo"

The output end is open: "ContHL"

Short circuit abnormal display: "SHORT"

Range overrun display: UNDER.F, OVER.F

Discharge current: 10mA Constant current discharge

Comparator: PASS / L.FAIL / U.FAIL

Setting up data preservation: Data can be recorded in 10 groups of panel settings

Trigger: IO triggers, manual triggers, bus triggers

IO Interface type: Can be configured as PNP or NPN

Interface:

External IO interface / analog output interface / LAN interface / Rs232 interface

Buzz sound, PASS / U.FAIL / L.FAIL LED light

UL_FAIL: U.FAIL / L.FAIL Light at the same time, EXT. I/O output, Get the decision result through RS-232

Power supply:

Voltage: 100V ~ 240V AC

Frequency: 50Hz/60Hz

Size and weight:

Size (W * H * D): 235mm x 105mm x 360mm

Weight: 2kg

Accessories: JK9921 / JK9800 / JK9600

Performance characteristics

1. The capacitive load can be charged and discharged quickly.

2. The test is stable and no additional shielding line is needed.

3. The connection detection function of the tested parts can prevent open circuit misjudgement.

4. Short circuit test before test to prevent high pressure breakdown.

5. Continuous test mode, PASS termination mode, FAIL termination mode, and mandatory termination mode.

6. Rich in interface, suitable for pipeline sorting.
