JFE UV-10 UV Meters (Organic contamination monitor) (UV: 255 nm, VIS: 660 nm)

Method: Absorptiometry

Light source: LEDs

Measurement wavelengths: UV: 255 nm, VIS: 660 nm

Measurement items:

Absorbance (UV, VIS, UV-VIS),

COD conversion values,

turbidity conversion values, and water temperature

Measurement range: Absorbance: 0.0 to 2.5 Abs

Accuracy (linearity): ±2%F.S. (±0.05Abs）

Reproducibility: ±2%F.S. (±0.05Abs）

Physical quantity (COD) conversion function: Correction using linear equation

Automatic zero point calibration: Equipped

Cleaning system: Automatic cleaning by a wiper

Sample water temperature range: 0 to 40℃ (freezing not allowed)

Water pressure limit: 1 MPa (100 m depth equivalent)

External dimensions: φ78×348mm（excluding protrusions）

Casing material: SUS316

Cable:

Material : PVC

Length :10m standard ( Up to 100m)

Weight: Approx. 3.7 kg (excluding cables)
