Jeiotech SK-71 Dual-Action Shakers

Model: SK-71
Manufacture: Jeiotech
Origin: Korea
warranty: 12 months

Control system Feedback control PID
Motion type Orbital or Reciprocating motion selectable
Frequency(RPM) 10 to 300
Timer Run time: 10 min to 999 hr 59 min 59sec
Forward & Backward, Pause: 10 sec to 59 min 59 sec
Orbit size (mm/inch dia.) 30, 40, 50, 60, 70mm
Available - Standard 30/1.2
Overall (W×L×H)(mm/inch) 820×610×170 mm
Net weight(Kg/lbs) 50kg
Electrical Requirements (230V, 50/ 60Hz) 0.2A
Cat. No. AAH31305K

Operating Features

• Microprocessor PID control
• Wide speed range: 10 ~ 300 rpm
• Dual shaking actions: orbital or reciprocating
• Additional shaking modes: Forward (clockwise rotation), Backward (counterclockwise rotation), and Pause
• Multi-step Programming of Shaking Operations:
  - Run time: 10 sec to 999 hr 59 min 59 sec.
  - Forward/Backward/Pause modes: 10 sec to 59 min 59 sec.
• Maximum orbit diameter
  - 40mm (1.6″) for SK-300, 600
  - 70mm (2.8″) for SK-71
• Bright LED displays with touch-sensitive keypad

Constructional Features

• Equipped with a maintenance-free direct drive BLDC motor to generate smooth, quiet, uniform, and yet powerful shaking motion required for high-speed applications and heavy workloads.
• Special acceleration and deceleration circuitry:
  - Stopping the shaking table always at the same position allowing for automated dosing or sampling.
  - Providing smooth start and smooth stop preventing chemical spills from flasks or test tubes.
• Low-profile design minimizing vibration or sliding caused by the high speed shaking motion.
• Chemicals-resistant and durable construction
• Various accessories
