JEIOTECH ON4-05S Natural Convection Oven (+15 ~ 250℃, 58L)

Chamber volume (L / cu ft): 58 / 2.05

Temperature

Range (℃ / ℉): Amb.+15 ~ 250℃ / Amb.+27 ~ 482℉

Fluctuation at 100℃ (℃ / ℉): ±0.5 / ±0.9

Variation at 100℃ (℃ / ℉): ±2.6 / ±4.68

Heating time to 100℃ (min.): 39

Recovery time at 100℃ (min.): 19

Control panel: 3.5 inch TFT Color LCD

Communication interface: USB-B, RS-232 (option)

Function Recently event record: 12 ea

Dimensions

Interior (W x D x H, mm / inch): 340 x 390 x 422 /13.4 x 15.35 x 16.61

Exterior (W x D x H, mm / inch): 558 x 648 x 684 / 21.97 x 25.5 x 26.93

Net weight (kg / lbs): 53 / 116.8

Shelves Quantity of shelves (standard/max.): 2 / 5

Max. Load per shelf (kg / lbs): 20 / 44.09

Number of air change per hour at 100℃: 16

Electrical requirements 230V, 50/60Hz, A: 3.5

Solid door without window

Datasheet
