Heating System: WELLER 151
Rated Power: 150W/200W
Move Stroke:
X: 600mm
Y1: 300mm
Y2: 300mm
Z: 100mm
R: 330°
Heating Range: 50°C ~ 500 °C
Weight: 60 kg
Dimension: 600 x 940 x 930 mm
Drive: Stepper motor + Synchronous belt roller + Slide way (Servo motor is optional)
Tin Wire O.D.: 0.5, 0.6, 0.8, 1.0, 1.2 mm
Work Plate: 160 x 220 mm, M4, Pitch 20 x 20 mm
Power Supply: AC 220V ± 10%, 50/60 Hz, 1000 VA
Program: Online Handheld Encoder
Memory Capacity: 1000
Process File: 1000
Safety Protection: Leakage protector, Overcurrent protector, Position limiter
Work Environment: 0-40°C, Humidity 20-90%, No condensation
External Control: IO Control
