JCW JCW-S600D EV Charging Cable Stripping Machine (0.1-200 mm)

Function: Coaxial cable, multistep stripping, rotary stripping, full stripping, partial stripping.

Raw material: PVC, Teflon, Silicone, Low halogen, Fiberglass, etc.

Cable diameter: 6-33 mm

Stripping length: 0.1-200 mm

Cutting depth increment: 0.01 mm

Blades: 4 pcs

Stripping steps: 9

Centralizer: Yes

Data library: Yes

OEM: Yes

Display: 4.3" color touchscreen, English / Chinese [other languages on request]

Rated power: 800 W

Power supply: AC 110/220 V ± 10%, 50/60 Hz

Dimensions: L 1000 x W 285 x H 500 mm

Weight: 108 KG

• Heavy-duty electric car charging cable

• Cable O.D. 6-33mm, stripping length 150/200 mm

• Multi-step stripping, max 9 steps

• Precise cutting and stripping, 0.01mm accuracy
