JCW JCW-QC20 Semi-Auto Terminal Cross Section Analyzer (AWG000-AWG46)
ManufacturerJCW(View more products from this manufacturer)
ModelJCW-QC20
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Analyzer: Imported continuous variable power optical system, objective lens magnification 0.7-4.5X
Video total magnification: 12-312X
Wire range: AWG000-AWG46 (0.008-75 mm²)
Clamp diameter: Max 20 mm
Accuracy: ±2 µm
Cutting blade: $100 x 0.5 mm
Cutting and grinding time: 2-3 minutes
Polishing sandpaper: 125 mm/1500#
Standard optical device: 0.1/10 mm
Imaging system: Balser, 3 megapixel CCD camera
Lighting: Tunable white lighting device
Rated power: 350 W
Power supply: AC 110V-220V, 50/60 Hz
