JCW JCW-F1 Wire Stripping Twisting & Ferrule Crimping Machine (17 mm, 6-12 mm)
ManufacturerJCW(View more products from this manufacturer)
ModelJCW-F1
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Conductor cross-section: 0.5, 0.75, 1.0, 1.5/2.5, 4.0 mm² [changing vibrate bowl]
Stripping length: Max 17 mm
Crimping shape: Quadrilateral [imitating square]
Crimping length: 6-12 mm
Cycle time: 2.5 seconds
Display: 4.3" color touchscreen, English / Chinese [other languages on request]
Customize logo: Yes
Data library: 8 programs
Air supply: 0.6-0.8 MPa (clean and dry air)
Power supply: AC 110V-220V±10%, 50/60 Hz
Dimensions: L 350 x W 450 x H 430 mm
Weight: 50 KG
