JCW JCW-CSO6F Reinfoced 4 Wires Automatic Cut & Strip Machine (2.5 mm², 0.1 - 999999 mm)

Function: Single wire, Multicore cable, Wire measuring, Cut length, Full stripping, Partial stripping, Mid-stripping, Cut depth, Wire run-out sensor, Length correction

Raw material: PVC, Teflon, Silicone, Low halogen, Fiberglass, etc

Conductor cross-sections: Max 2.5 mm² x 4 wires

Cutting length (L): 0.1 - 999999 mm

Cutting length accuracy: 0.002 x L

Stripping length:

Front (right) side: 150 mm [partial stripping]

Rear (left) side: 70 mm [partial stripping]

Middle strip: 13 sections

Production rate: 10000 pcs/h by 100 mm wire length

Data library: 100 programs

Display: 4.3" color touchscreen, English / Chinese [other languages on request]

Cable feeding: 6 rollers

Compatible peripherals: Cable prefeeding unit, robot arm, cable stacker

Power supply: AC 110 - 220 V ± 10%, 50 / 60 Hz

Air supply: 0.4 - 0.7 MPa (clean and dry air)

Dimensions:

Machine: L 560 x W 470 x H 370 mm

Wire straightener: 250 mm

Weight: 45 KG

CE-Conformity: Complies with CE equipment guidelines relative to mechanical and electrical safety and electromagnetic compatibility

• Single wire model of CS06

• Process 4 single wires in one work step

• Each wire max 2.5mm²

• High productivity, increased efficiency
