JCW JCW-CS600B 15mm Length Coax Cable Automatic Cut and Strip Machine (15 - 200 mm, 50 mm, 30 mm)

Function: Single wire, multicore cable, coax cable, cut length, cut depth, data library, workbench

Cable diameter: 1.0 - 6.0 mm

Cutting length (L): 15 - 200 mm

Cutting accuracy: L ± 2%

Cut depth increment: 0.01 mm

Stripping length:

Lead side: max 50 mm

Rear side: max 30 mm

Stripping accuracy: 0.02 mm

Stripping steps: 6

Product rate: 400 - 750 pcs/h [Depending on cable type]

Data library: 40 programs

Power supply: AC 110 - 220 V ± 10%, 50 / 60 Hz

Rated power: 800 W

Display: 7" color touch screen, English / Chinese [customizable]

Dimensions: L 790 x W 730 x H 400 mm

Weight: 110 KG

• Ultra-short cutting length 15-200mm

• Rotary cutter head, wide cable range

• Cable diameter ranging from 1.0 to 6.0mm

• Customizable to 8.5mm diameter coax cable

• Automatic product line, professional cable prefeeder
