JCW JCW-2TU 40MM Servo Motor Press Wire Stripping Crimping Machine (1 - 6 mm, 2 tons)

Function: Single wire, Multiconductor cable, Wire stripping, Terminal crimping, Side/horizontal feed terminal

Raw material: PVC, Teflon, Silicone, Low halogen, Fiberglass, etc

Crimp force: 2 tons [Customizable]

Conductor cross-sections: 0.03 - 2 mm² [AWG 32 - 14] [Customizable]

Stripping length: 1 - 6 mm

Accuracy: 0.05 - 0.1 mm

CFM: Compatible

Crimp press: Mitsubishi servo control

Rated power: 750 W

Power supply: AC 220 V ± 10%, 50 / 60 Hz

Air supply: 0.3 - 0.6 MPa (clean and dry air)

Dimensions: L 730 x W 550 x H 1350 mm

Weight: 100 KG

• Non-insulated, side-feed, open barrel, reel terminal

• AMP/TE / JAM / YAZAKI crimping applicator

• Servo motor control press

• PLC control system

• Touch screen
