JASIC MIG350(J1601) MIG Welding Machine

Rated input voltage (V/Hz): 3 Phase AC380V±15%, 50/60

Rated input current: 21 A

Rated power: 14 KVA

Welding current adjustment range: 50 – 350 A

Output voltage adjustment range: 15 - 36 V

No-load voltage: 60 V

Load cycle Imax 40°C: 60%

Power factor cosφ: 0.93

Efficiency: 85%

Wire feed speed: 1.5-16 m/min

Wire diameter: 0.8/1.0/1.2 mm

Protection level: IP21S

Insulation level: F

Included accessories:

WF-23A wire feeder

35mm welding cable 5m long

36KD welding gun 3m long

Cooling clamp with 3m long welding cable;

CO2 meter
