INSIZE OES-R530 Spark Direct Reading Spectrometer (Standard Type) (130~800nm)

Optical System

Spectral Range: 130 ~ 800 nm*

Lightroom Material: Cast iron

Detector: Multiple CCD detectors, unlimited maximum number of detection channels

Optical System Construction: Paschen-Runge construction, grating focal length 500 mm, Roland circle diameter: 500 mm

Raster Scribing: 2700 lines/mm

Resolution: Better than 0.01 nm (line resolution 0.7407 nm/mm, pixel resolution 0.005926 nm)

Pixel Dimension: 8 μm

Dispersion: Class I: 0.74 nm/mm, Class II: 0.37 nm/mm

Curve

Standard Curve: Carbon steel/low and medium alloy steel (A1), plain stainless steel (A2), Al-Si-Cu alloy (B1)

Customized Curve: Curves can be added or customized for special base materials (Mg, Ti, Pb, Sn, Mn, etc.)

Excitation Source

Excitation Frequency: 20 – 1000 Hz

Excitation Current: 90 A

Excitation Voltage: 190 V

Spark Stand

Discharge Parameter: Inductance: 120 µH, Resistance: 3.50, Capacitance: 5 µF, Voltage: 380 V

Dimension: 125 × 95 mm, Max. load 50 kg

Lens: One-piece lens isolation valve

Excitation Electrode: Tungsten electrode

Gas Supply

Argon Quality: Purity: 99.999%, Pressure: 20.6 MPa

Flow Rate: Tidal flushing mode, excitation: 8 L/min, standby: 60 ml/min

General Analysis Time: <40 s

Data Processing: After instrument excitation, acquisition and countback to independently control the integration exposure time of different CCDs

Work Environment: 20 – 25°C, <70% RH

Power Supply: AC 220V, 50 Hz, 10/16A, 2.5 KW, ground resistance <40

Dimension (W × D × H): 470 × 872 × 435 mm

Weight: 100 kg

*The instrument can be optionally equipped to analyze elements N, Li, Na, and K.

Datasheet

STANDARD DELIVERY

Main unit: 1 pc

Computer: 1 set

Printer: 1 pc

Voltage regulator: 1 pc

Calibration sample: 1 set

Electrode brush (OES-T350-BR): 1 set

Analysis and calibration software: 1 set

Consumable and spare parts: 1 set *

* Including polarimeter, pressure reducing valve, electrode brush and other consumable and spare parts
