INSIZE ISU-710D Ultrasonic Thickness Gage (For Thick Workpieces made of organic materials) (20~590mm)

Measuring range: 20~590mm

Measuring unit: mm/inch

Resolution: 0.1/0.01mm

Accuracy:

- ±(0.3%H)mm (H>100mm)

- ±(0.04+0.1%H)mm (H: 10~99.9mm)

- H is the thickness to be measured in mm

Transducer:

- Type: Monocrystal probe

- Frequency: 1.0MHz

- Diameter (Ød): 26mm

Display: 320x240, color screen display

Velocity: 1000~9999m/s

Measuring frequency: 2 times/sec and 10 times/sec

Applicable temperature: -20~50oC

Output: USB

Power supply: 2x1.5V AA batteries

Dimension: 133x75x29mm

Weight: 260g (including batteries)
