INSIZE ISR-S300 Roughness Tester

Automatic probe leveling

Language: English, French, German, Italian, Spanish, Portuguese

12 roughness parametrers

Can set tolerence

Measuring range up to 100um, can measure grit and shot blasting.

Traverse length up to 16mm

The probe can rotate from 90 °or 270 ° for transerve measurement

Memory of maximum 100 results

Remark: probe can't be changed

Parameters: Ra, Rq, Rt, Rz, Rmax, Rsm, Rpc, Rmr, R, AR, Rx

Range: Ra: 0-100um, Rt: 0.05-400um

Accuracy: +-3%

Resolution (Ra): 0.001um

Probe type: inductive

Probe Stylus radius/ angle: 5um/90 °

Probe stylus material: diamond

Measuring force: 0.75mN

Measuring unit: um/uin

Cut off: 0.25/0.8/2.5mm

Numbers of cut-offs: 1-5

Traverse speed: 1mm/s

Memory: 100 measurement results

Output: USB

Power: built-in rechargeable results

Dimension: 122x52x68m

Weight: 650g

Datasheet
