INSIZE ISE-DF10 Digital gap gauge

Name: INSIZE ISE-DF10 Digital gap gauge
Brand: INSIZE

ModelISE-DF10

Contact

Quantity

Secure Checkout

Quality Engagement

Easy change and return

Delivery Available

Specification:

Code:ISE-DF10

Resolution:0.1/0.01/0.001mm

Accuracy:±0.03mm

RAM:8GB

Output:USB, WiFi

Output format:XML, CSV

Probe (optional) specification:

Customisable measurement range:0.35-6mm

Effective range:±0.5mm

Accuracy:range: 0.35~2.0mm, accuracy: ±0.03mm range: 0.35~6.0mm, accuracy: ±0.04mm

Maximum customisable probe length:500mm

Repetitive:0.02mm

Measurement force:<3.5N

Measurement time:<1s

■ Compliance with corporate standards

■ Real-time measurement: display maximum value, minimum value current measurement value and measurement curve.

■ Group measurement: Target value and upper and lower tolerance can be set, automatic judgement of OK and NG.

Datasheet
