Infineon BCR 146 E6327 Digital Transistors NPN Silicon Digital TRANSISTOR
ManufacturerInfineon(View more products from this manufacturer)
ModelBCR 146 E6327
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Width: 1.3 mm
Height: 1 mm
Length: 2.9 mm
Unit Weight: 8 mg
Configuration: Single
Mounting Style: SMD/SMT
Transistor Polarity: NPN
Pd - Power Dissipation: 200 mW
Typical Input Resistor: 47 kOhms
Typical Resistor Ratio: 2.14
Peak DC Collector Current: 70 mA
Emitter- Base Voltage VEBO: 50 V
Continuous Collector Current: 70 mA
Maximum DC Collector Current: 70 mA
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 65 C
DC Collector/Base Gain hfe Min: 50
Collector- Emitter Voltage VCEO Max: 50 V
