iKAM iK-6011C High Performance Benchtop DC Electronic Load (80V; 20A; 150W)

Voltage: 80V

Current: 20A

Power: 150W

Min. Operating Voltage: 0.4V@2A/ 1V@20A

CV Mode:

Range: 0~8V/ 0~80V

Setting Resolution: 0.1mV/ 1mV

Setting Accuracy (23±5℃): 0.025%+0.025%F.S.

Readback Resolution: 10μV/ 0.1mV

Readback Accuracy (23±5℃): 0.025%+0.025%F.S.

CC Mode:

Range: 0~2A/ 0~20A

Setting Resolution: 0.1mA/ 1mA

Setting Accuracy (23±5℃): 0.05%+0.05%F.S.

Readback Resolution: 10μA/ 0.1mA

Readback Accuracy (23±5℃): 0.05%+0.05%F.S.

CP Mode:

Range: 15W/ 150W

Setting Resolution: 1mW/ 10mW

Setting Accuracy (23±5℃): 0.1%+0.1%F.S.

Readback Resolution: 0.1mW/ 1mW

Readback Accuracy (23±5℃): 0.1%+0.1%F.S.

Range: 1Ω~18kΩ/ 0.1Ω~1.8kΩ

Test Setting Resolution: 1Ω/ 0.1Ω

Setting Accuracy (23±5℃): (Vin/Rset)*0.1%+0.1%IF.S.

Slew Rate:

Current: 0.2~200A/ms/ 2~2000A/ms

Power: 0.2~200A/ms/ 2~2000A/ms

Resistance: 0.2~200A/ms/ 2~2000A/ms

Dynamic Mode:

T1&T2: 0.016ms~60000ms/0.016s~60000s

Resolution: 1μs/1ms

Rise/fall slew rate: 0.2~200A/ms/ 2~2000A/ms

Others:

Protection Function: OVP/OCP/OPP/OTP/RV

Interface: LAN/RS232

Communication Protocol: Modbus-RTU standard protocol, SCPI standard protocol, TCP/IP protocol

Response Time: ≤5ms

AC Input: Voltage 110/220V AC, frequency 47Hz~63Hz, current ≤0.25A@220V ≤0.5A@110V

Temperature: Operating temperature: 0℃~40℃, storage temperature: -20℃~60℃

Operating Environment: Altitude <2000m, relative humidity: 5%~90%RH(non-condensing), atmospheric pressure: 80~110kPa

Net Weight: Approx.4.5kg

Dimension: 88.0(H)*214.0(W)*363.0(D) mm
