iKAM iK-6080G1 Wide Range High Power Programmable DC Power Supply (90kW/80V/3060A)

Voltage: 0~80V

Current: 0~3060A

Power: 0~90kW

CV Mode:

Range: 0~80V

Setting Accuracy (23±5°C): 0.05%+0.05%F.S.

CC Mode:

Range: 0~3060A

Setting Accuracy (23±5°C): 0.1%+0.1%F.S.

CP Mode:

Range: 0~90kW

Setting Accuracy (23±5°C): 1%F.S.

Voltage Measurement:

Range: 0~80V

Readback Accuracy (23±5°C): 0.05%+0.05%F.S.

Current Measurement:

Range: 0~3060A

Readback Accuracy (23±5°C): 0.1%+0.1%F.S.

Line Regulation:

Voltage: ≤0.01%F.S.

Current: ≤0.05%F.S.

Load Regulation:

Voltage: ≤0.02%F.S.

Others:

Interface: Standard: RS232/LAN, optional: RS485/CAN/GPIB/USB

Protocol: SCPI/MODBUS-RTU/CAN-Open

AC Input: Three phase 340VAC~460VAC, frequency 47Hz~63Hz

Communication Response Time: ≤5ms

Power Factor: 0.99(Typical)

Temperature: Operating temperature: 0°C~40°C, storage temperature: -20°C~70°C

Operating Environment: Altitude <2000m, relative humidity: 5%-90%RH(non-condensing), atmospheric pressure: 80-110kPa

Size: 19inch/18U

Datasheet
