iKAM iK-6020F Portable Wide Range Programmable DC Power Supply (0.5~81V; 0~8.2A; 200W)

Voltage: 0.5~81V

Current: 0~8.2A

Power: 200W

CV Mode:

Range: 0.5~81V

Setting Resolution: 10mV

Setting Accuracy: 0.05%+10mV

CC Mode:

Range: 0~8.2A

Setting Resolution: 1mA

Setting Accuracy: 0.2%+5mA

Voltage Measurement:

Range: 0.5~81V

Readback Resolution: 10mV

Readback Accuracy: 0.05%+10mV

Temperature Coefficient: 50ppm/°C

Current Measurement:

Range: 0~8.2A

Readback Resolution: 1mA

Readback Accuracy: 0.2%+5mA

Temperature Coefficient: 50ppm/°C

Line Regulation:

Voltage: <0.01%+3mV

Current: <0.1%+5mA

Load Regulation:

Voltage: ≤30mV

Current: ≤10mA

Dynamic Characteristics:

Voltage Rise Time (no load): ≤300ms

Voltage Rise Time (full load): ≤300ms

Voltage Fall Time (no load): ≤500ms

Voltage Fall Time (full load): ≤300ms

Transient Recovery Time: ≤5ms

Output Ripple&Noise(20Hz-20MHz):

Voltage: ≤10mVrms

Current: ≤8mArms

Others:

AC Input: Single phase, 100~240VAC, frequency 47Hz~63Hz

Operating Environment: Altitude <2000m, relative humidity: ≤80%(non-condensing), atmospheric pressure: 80~110kPa

Storage Temperature: -10°C~70°C，≤70%(non-condensing)

Interface: RS232/RS485/LAN

Net Weight: Approx. 1.8kg

Dimension: 55.0(W)*315.0(D)*140.0(H)mm
