iKAM iK-6010E High Performance Benchtop Programmable DC Power Supply (0~40V; 0~50A; 900W)

Voltage: 0~40V

Current: 0~50A

Power: 900W

Channels: 1CH

CV Mode:

Range: 0~40V

Setting Resolution: 1mV

Setting Accuracy (23±5°C): ≤0.03%+0.02%F.S.

Voltage Ripple(20Hz-20MHz): ≤40mVp-p

CC Mode:

Range: 0~50A

Setting Resolution: 1mA

Setting Accuracy (23±5°C): ≤0.1%+0.1%F.S.

Current Ripple(20Hz-5MHz): ≤50mArms

CP Mode:

Range: 900W

Setting Resolution: 0.01W

Setting Accuracy (23±5°C): 0.5%F.S.

Voltage Measurement:

Range: 0~40V

Readback Resolution: 1mV

Readback Accuracy (23±5°C): ≤0.03%+0.02%F.S.

Current Measurement:

Range: 0~50A

Readback Resolution: 1mA

Readback Accuracy (23±5°C): ≤0.1%+0.1%F.S.

Line Regulation:

Voltage: <0.02%F.S.

Load Regulation:

Voltage: <0.05%F.S.

Dynamic Characteristics:

Voltage Rise Time(no load): ≤10ms

Voltage Rise Time(full load): ≤10ms

Voltage Fall Time(no load): ≤25ms

Voltage Fall Time(full load): ≤10ms

Transient Recovery Time: The output voltage recovering within 0.5% of the rated output voltage value（10%~90% load)≤2ms

Others:

Isolation(Output to Ground): 500V DC

Max. Efficiency: 0.91

Power Factor: 0.99

Interface: LAN/RS232/RS485/CAN

Communication Response Time: ≤5ms

AC Input: 220V AC±10%,47Hz~63Hz,≤10A

Temperature: Operating temperature: 0°C~40°C, storage temperature: -10°C~70°C

Operating Environment: Altitude <2000m, relative humidity: 5%~90%RH(non-condensing), atmospheric pressure: 80~110kPa

Net Weight: Approx. 5kg

Dimension: 88.0(H)*214.0(W)*413.5(D)mm, with output shield
