iKAM iK-6500C4 High Performance High Power Bidirectional Programmable DC Power Supply (1000V/585A/252kW)

Voltage: 0~1000V

Current : -585A~+585A

Power: -252kW~+252kW

CV Mode:

Range: 0~1000V

Setting Resolution: 10mV

Setting Accuracy(23±5°C): ≤0.02%+0.02%F.S.

Voltage Ripple(20Hz-20MHz) : ≤2Vp-p;  ≤400mVrms

CC Mode:

Range: -585A~+585A

Setting Accuracy(23±5°C): ≤0.1%+0.1%F.S

CP Mode:

Range: -252kW~+252kW

Setting Resolution: 0.1W

Setting Accuracy(23±5°C): ≤0.1%+0.1%F.S.

Voltage Measurement:

Range: 0~1000V

Readback Resolution: 10mV

 Readback Accuracy(23±5°C): ≤0.02%+0.02%F.S

Temperature Coefficient: ≤15ppm/°C

Current Measurement:

Range: -585A~+585A

Readback Accuracy(23±5°C): ≤0.1%+0.1%F.S.

Temperature Coefficient: ≤30ppm/°C

Dynamic Characteristics:

Voltage Rise Time (no load 10%~90%) : ≤5ms

Voltage Rise Time (full load 10%~90%) : ≤5ms

 Voltage Fall Time (no load 90%~10%) 1: ≤10ms

Voltage Fall Time (full load 90%~10%): ≤5ms

Transient Response Time: The recovery time of load varying from 10% to 60% and output voltage recovering within 0.75% of rated voltage is less than 1ms.

Line Regulation:

Voltage: <0.01%F.S.

Current: <0.02%F.S.

Load Regulation:

Voltage: <0.01%F.S.

Current: <0.05%F.S.

Others:

Isolation (Output to ground): 1500V DC

Max. Efficiency: 93%

Power Factor: 0.99

Protection: OVP/OCP/OPP/UVP/UCP

Interface: LAN/RS232/RS485/CAN

Communication Response Time: 5ms

Temperature: Operating temperature: 0°C~50°C (>35°C derating output); Storage temperature: -10°C~70°C

Operating Environment: Altitude <2000m; relative humidity:5%~90%RH(non-condensing); atmospheric pressure: 80~110kPa
