iKAM iK-6050B Bidirectional Programmable DC Power Supply (0~80V; -110A~+110A; -5000W~+5000W)

Voltage: 0~80V

Current: -110A~+110A

Power: -5000W~+5000W

Minimum Operating Voltage: 2V@110A

CV Mode:

Range: 0~80V

Setting Resolution: 1mV

Setting Accuracy(23±5°C): 0.02%+0.02%F.S.

Readback Resolution: 1mV

Readback Accuracy(23±5°C): 0.02%+0.02%F.S.

CC Mode:

Range: -110A~+110A

Setting Resolution: 1mA

Setting Accuracy(23±5°C): 0.1%+0.1%F.S.

Readback Resolution: 1mA

Readback Accuracy(23±5°C): 0.1%+0.1%F.S.

CP Mode:

Range: -5000W~+5000W

Setting Resolution: 0.1W

Setting Accuracy(23±5°C): 0.5%+0.5%F.S.

Readback Resolution: 0.1W

Readback Accuracy(23±5°C): 0.5%+0.5%F.S.

CR Mode:

Range: 0.01~800Ω

Setting Resolution: 10mΩ

Setting Accuracy(23±5°C): (Vin/Rset)*0.1%+0.1%IF.S.

Series Internal Resistance Settings:

Range: 0~1.2Ω

Setting Resolution: 10mΩ

Setting Accuracy(23±5°C): ≤1%F.S.

Dynamic Characteristics:

Voltage Rise Time (no load 10%~90%): ≤10ms

Voltage Rise Time (full load 10%~90%）: ≤30ms

Voltage Fall Time (no load 90%~10%): ≤30ms

Voltage Fall Time (full load 90%~10%): ≤10ms

Transient Response Time: ≤1ms(25%~90% load variation)

Line Regulation:

Voltage: ≤0.01%+0.01%F.S.

Current: ≤0.03%+0.03%F.S.

Load Regulation:

Voltage: ≤0.01%+0.01%F.S.

Current: ≤0.05%+0.05%F.S.

Temperature Coefficient:

Voltage: ≤30ppm/°C

Current: ≤50ppm/°C

Ripple Noise（20Hz~20MHz）:

Ripple(P-P): ≤200mV

Ripple(rms): ≤80mV

Others:

Efficiency: 0.92

Power Factor: 0.99

Current Harmonic: ≤5%

Protection: OVP/OCP/OPP/UVP/UCP

Interface: LAN/RS232/RS485/CAN

Communication Response Time: 5ms

Isolation(Output to Ground): 500V DC

AC Input: 380V AC±10%, frequency 47Hz~63Hz, current≤10A

Temperature: Operating temperature: 0°C~40°C; Storage temperature:-10°C~70°C

Operating Environment: Altitude <2000m; relative humidity: 5%~90%RH(non-condensing); atmospheric pressure: 80~110kPa

Net Weight : Approx. 13kg

Dimension: 44.0mm(H)*428.0mm(W)*711.2(D)(with shield）
