iKAM iK-6080A DC power supply (3CH; 338W)

Channel: CH1/CH2

Voltage: 32V

Current: 5A

Series Mode-Voltage: 64V

Parallel Mode-Current: 10A

Total Power: 338W

Setting Resolution-Voltage: 10mV

Setting Resolution-Current: 1mA

Setting Accuracy-Voltage (23±5°C): ＜0.01%＋20mV

Setting Accuracy-Current (23±5°C): ＜0.05%＋20mA

Setting Temperature Coefficient: 50ppm/℃

Readback Resolution-Voltage: 10mV

Readback Resolution-Current: 1mA

Readback Accuracy-Voltage (23±5°C): ＜0.01%＋20mV

Readback Accuracy-Current (23±5°C): ＜0.05%＋20mA

Readback Temperature Coefficient: 50ppm/℃

Long-term Stability: ≤50ppm/1000h

Voltage Ripple Noise (20Hz～20MHz): ≤5mVp-p

Voltage Ripple Noise (20Hz～20MHz): ≤1mVrms

Current Ripple Noise (20Hz～20MHz): ≤3mArms

Dynamic Characteristics:

Voltage Rise Time (no load) (10%-90%F.S. Variation Time): 20ms

Voltage Rise Time (full load) (10%-90%F.S. Variation Time): 50ms

Voltage Fall Time (no load) (90%-10%F.S. Variation Time): 400ms

Voltage Fall Time (full load) (90%-10%F.S. Variation Time): 45ms

Transient Recovery Time: ≤1ms

Line Regulation-Voltage: ≤0.01%+1mV

Line Regulation-Current: ≤0.01%+3mA

Load Regulation-Voltage: ≤0.01%+3mV

Load Regulation-Current: ≤0.01%+3mA

Channel: CH3

Voltage: 6V

Current: 3A

Series Mode-Voltage: N/A

Parallel Mode-Current: N/A

Total Power: 338W

Setting Resolution-Voltage: 1mV

Setting Resolution-Current: 1mA

Setting Accuracy-Voltage (23±5°C): ＜0.03%＋10mV

Setting Accuracy-Current (23±5°C): ＜0.05%＋10mA

Setting Temperature Coefficient: 50ppm/℃

Readback Resolution-Voltage: 1mV

Readback Resolution-Current: 1mA

Readback Accuracy-Voltage (23±5°C): ＜0.03%＋10mV

Readback Accuracy-Current (23±5°C): ＜0.05%＋10mA

Readback Temperature Coefficient: 50ppm/℃

Long-term Stability: ≤50ppm/1000h

Voltage Ripple Noise (20Hz～20MHz): ≤10mVp-p

Voltage Ripple Noise (20Hz～20MHz): ≤1mVrms

Current Ripple Noise (20Hz～20MHz): ≤3mArms

Dynamic Characteristics:

Voltage Rise Time (no load) (10%-90%F.S. Variation Time): 20ms

Voltage Rise Time (full load) (10%-90%F.S. Variation Time): 21ms

Voltage Fall Time (no load) (90%-10%F.S. Variation Time): 200ms

Voltage Fall Time (full load) (90%-10%F.S. Variation Time): 13ms

Transient Recovery Time: ≤1ms

Line Regulation-Voltage: ≤0.01%+3mV

Line Regulation-Current: ≤0.02%+3mA

Load Regulation-Voltage: ≤0.01%+3mV

Load Regulation-Current: ≤0.02%+3mA

Others:

Isolation (Output to Ground): 500V DC

Communication Response Time: ≤5ms

Interface: LAN/RS232

AC Input: Single phase, 220V AC±10%, frequency 47Hz~63Hz

Temperature: Operating temperature: 0°C~40°C, storage temperature: -20°C~60°C

Operating Environment: Altitude <2000m, relative humidity: 5%~90%RH(non-condensing), atmospheric pressure: 80~110kPa

Net Weight: Approx. 11kg

Dimension: 2U, 88.0(H)*214.0(W)*446.0(D)mm
