iKAM iK-91003PL Programmable DC Power Supply (100V; 3A)

1.Rated Operating Conditions:

Operating Voltage: AC220V±10%  50Hz

Operating Conditions: Temp0～40℃             Relative Humidity: ≤80%RH

Storage Conditions: Temp-20～60℃             Relative Humidity: ≤80%RH

 Temperature Range for Guaranteed Accuracy: 23℃±5℃

2.Technical Specifications

Max. Voltage: 100V

Max. Current: 3A

Voltage:

Setting Resolution: ＜100V: 10mV; ≥100V: 0.1V

Setting Accuracy: ≤0.1%+5digits

Readback Resolution: ＜100V: 10mV; ≥100V: 0.1V

Readback Accuracy: ≤0.1%+5digits

Temp. Coefficient: ≤0.02%+3mV

Ripple: ≤18mVrms

Current:

Setting Resolution: ＜10A: 1mA; ≥10A: 10mA

Setting Accuracy: ≤0.2%+10digits

Readback Resolution: ＜10A: 1mA; ≥10A: 10mA

Readback Accuracy: ≤0.2%+10digits

Temp. Coefficient: ≤0.02%+3mA

Ripple: ≤18mArms

Load Regulation: <10A: ≤0.1%Umax+5mV; ≥10A: ≤0.2%Umax+5mV

Line Regulation: <10A: ≤0.1%Umax+5mV; ≥10A: ≤0.2%Umax+5mV

OVP: 0-103V

OCP: 3.5A

Power Input: AC 220V±10%, 50Hz (Optional:  Fixed AC110V input;  or AC110V/220V switchable input)

Accessories: Power cord x1,  5A clip lead x1,  Manual x1,  Certificate x1

Cooling Method: Air Cooled

Weight: ≤2.2KG

Unit Dimensions (LxWxH): 280(D)×130(W)×165(H)mm

Package Dimensions (LxWxH): 355(D)×178(W)×210(H)mm

 Note:  Please ensure warm-up time over 10 minutes when using these specifications.
