IFM Electronic OGE700 Through-Beam Sensor Receiver (60m; 655nm)

Type of light: red light

Housing: rectangular

Function principle: Through-beam sensor

Operating voltage [V]: 10...36 DC

Current consumption [mA]: 11

Protection class: II

Reverse polarity protection: yes

Wave length [nm]: 655

Electrical design: PNP

Output function: light-on/dark-on mode; (programmable)

Max. voltage drop switching output DC [V]: 2.5

Permanent current rating of switching output DC [mA]: 200

Switching frequency DC [Hz]: 1000

Short-circuit protection: yes

Type of short-circuit protection: pulsed

Transmitter / receiver: receiver

Range [m]: < 60

Range adjustable: yes

Diameter of the smallest detectable object [mm]: 3; (60 m)

Ambient temperature [°C]: -10...60

Protection: IP 65; IP 67

Weight [g]: 61.9

Dimensions [mm]: M18 x 1 / L = 72

Materials: stainless steel (1.4404 / 316L); PA; LCP; EPDM; TPU

Lens material: PMMA

Display: switching status 1 x LED, yellow

Items supplied: lock nuts: 2 x

Connection: Connector: 1 x M12; coding: A
