iDRC DSP1300-23WS DC Solar Array Simulator (10kW, 1300V, 23A)

Output voltage

Rated value (V1): 0 ~ 1300V

Settable range: 0 ~ 1365V

Output current

Rated value (A1): 0 ~ 23A

Settable range: 0 ~ 24.15A

Output power

Rated value: 0 ~ 10kW

Settable range: 0 ~ 10200W

Internal resistance

Adjustment range: 0 ~ 56.521Ω

Insulation

Primary - Chassis: 2.5 kV DC

Primary - Secondary: 2.5 kV DC

Secondary - Chassis: 2000VDC

Operating temperature: 0°C ~ 50°C

Humidity: 30%RH ~ 80%RH (no condensation) Max 80% RH up to 30°C, linear decrease to 50% RH at 40°C

Storage temperature: -20°C ~ 70°C

Input

Input voltage range: 180VAC ~ 460VAC, Optional 480VAC (type:432VAC ~ 528VAC)

Input frequency range: 47Hz ~ 63Hz

Current (Maximum): 40A / Phase (Input 3-phase 180V)

Inrush current (Maximum): 66A / Phase (Input 3-phase 460V)

Input Power (Maximum): 12kVA

Interface

Standard: LAN, J1

Optional: Analog, RS-485, GPIB

Size and Weight

Total (WxHxD): 482 x 132 x 765.1 mm

Weight (kg): 34.8
