iDRC DSP-600-100HP Programmable DC Power Supply (60kW, 600V, 100A)

Capacity: 60kW

CV: 600V

CC: 100A

AC Input (3Ø 380V 50/60Hz): Power - VA: 75kVA

Line regulation

Voltage: ± 0.04% of full scale

Current: ± 0.08% of full scale

Load regulation

Voltage: ± 0.05% of full scale

Current: ± 0.1% of full scale

Over voltage / Over current setting range: 0% ~ 110% of rated voltage; 0% ~ 110% of rated rated current

Withstand voltage

Primary - Chassis: No abnormalities AC 2000V for 1 minute

Primary - Secondary: No abnormalities AC 2000V for 1 minute

Secondary - Chassis: No abnormalities DC 1200V for 1 minute

Weight: Approx. 580kg

Size: 35UE

Operating Temperature: 0~40℃; 30%~90%RH (no condensation)

Storage environment: -20~70℃; 10%~90%RH (no condensation)

Interface

Standard: Standard GPIB and Isolation RS-485 Interface.

Option: Analog Programming and monitoring, isolated type.

Optional Items:

HP-OPT-RMS: True RMS Current & True Watt

HP-OPT-API: Analog Programming interface

HP-OPT-CP: Constant Power

HP-OPT-IS: Impedance Simulation

HP-OPT-PS: Parallel & Series Controller
