iDRC DSP-600-01.25HR Programmable DC Power Supply (750W, 600V, 1.25A)

Output power: 750W

Output

Voltage: 0 - 600 V

Current: 0 - 1.25 A

Input

Input voltage: 100~240Vac, 50/60Hz

Input current (Full load): 115Vac - 8.1A ; 230Vac - 4.1A ;

Inrush current: 230Vac <17A

Line regulation

0.05%+mV: 62

0.1%+mA: 2.13

Load regulation

0.05%+mV: 62

0.1%+mA: 5.26

Efficiency: 76% ‒ 87% ;

Power Factor (PF): 0.99 (at 115Vac, rate output)

Withstand voltage

Input-Output - AC2000V:1 minute

Input-Ground - AC2000V:1 minute

Weight: 1UH type : approx. 5.1 kg ,

Noise: <70 dB(A)

Operating environment: Temperature : 0~40℃ ; Humidity : 30%~90% RH(no condensation)

Storage environment: Temperature : -20~70℃ ; Humidity : 10%~90% RH (no condensation)
