IDEC RV8S-S-D48-A120 SSR 6mm SSR 120VAC input
ManufacturerIDEC(View more products from this manufacturer)
ModelRV8S-S-D48-A120
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Width: 6.1 mm
Height: 74.2 mm
Length: 88 mm
IP Rating: IP20
Output Type: Triac
Input Current: 10 mA
Mounting Style: DIN Rail Mount
Termination Style: Screw
Relay Contact Form: 1 Form A (SPST-NO)
Load Current Rating: 100 mA
Load Voltage Rating: 48 VDC
Control Voltage Range: 96 VAC to 132 VAC
Maximum Operating Temperature: + 60 C
Minimum Operating Temperature: - 20 C
