ICW ICW95130BLE Handheld Barcode Reader (45°(H) x 35°(V); 360°, ±65°, 60°)

Size: 180mm * 95mm * 70mm

Weight: 212g

Voltage and current: 5VDC ±10% @500mA

Sensor pixel: 640 pixels(H) * 480 pixels(V)

Light source: Aiming: 617nm LED, illumination: 6500K LED

Field of view: Horizontal 45°(H) x Vertical 35°(V)

Rotate / Tilt / Deflection: 360°, ±65°, 60°

Battery capacity: 4.2V / 2500mAh

Charging time: 5-6H

Battery life: 1S scan once, can work continuously for 18H

Wireless technology: Bluetooth 4.0

Operating distance: 100 meters (open space)

Print contrast: Minimum 25% reflection difference

Motion tolerance: Up to 25 in. (63.5cm) per second

Interface support: USB, RS232

Support one-dimensional barcode (1-D): UPC, EAN, Code128, Code39, Matrix 2 of 5, Interleaved 2 of 5, Codabar, MSI Plessey, GS1 DataBar, China Postal, Korean Postal, etc.

Support two-dimensional barcode (2-D): PDF417, MicroPDF417, Data Matrix, Maxicode, QR Code, MicroQR, Aztec, Hanxin, etc.

Operating temperature: 0°C to 50°C

Storage temperature: -40°C to 70°C

Humidity: 0% to 95% (no condensation)

Anti-vibration: Designed to withstand 1.5m (5') drops

Ambient light immunity: 1000,000 lux

Decoding Range:

5mil (Code39): 50mm - 110mm

13mil (100% UPC-A): 30mm - 3000mm

1D Minimal Resolution: 4mil
