iBASE Technology MB995VF-C246 Single Board Computers ATX, LGA1151 Xeon & Core i7/i5/i3, C246 PCH, I219LM+Intel I210AT GbE, VGA (HDMI 2.0/DVI-D/DisplayPort), SATAIII x6, COM x 6 (RS232/422/485 x2+RS232 x4), PCIe(16x)+PCIe(4x)+PCIe(1x)+ 3 x PCI, Mini PCIe + M.2(M-key) + M.2(E-key), iAMT11.6 ,TPM(2.0), iS

Core: Core i3/i5/i7, Xeon E

Chipsets: C246

Frequency: 4.7 GHz

Dimensions: 305 mm x 244 mm

Form Factor: ATX

Memory Type: DDR4-2666

Installed RAM: 0 GB

Interface Type: Audio, DP, DVI-D, Ethernet, HDMI, mPCIe, PCI, PCIe, RS-232/422/485, SATA, USB 2.0, USB 3.0, USB 3.1

Processor Type: Core i3/i5/i7, Xeon E

Processor Brand: Intel

Maximum RAM Capacity: 64 GB

Operating Supply Voltage: 3.3 V, 5 V, 12 V

Maximum Operating Temperature: + 60 C

Minimum Operating Temperature: 0 C
