IAS Analysis IAS-6100 Portable NIR Analyzer (950–1650 nm)

Wavelength Range: 950–1650 nm

Resolution: 12 nm

Spectroscopic Principle: Array MEMS Micromirror + Grating

Detector: InGaAs Detector

Baseline Noise: ≤ 0.0005 AU

Wavelength Repeatability: ≤ 0.05 nm

Wavelength Accuracy: ≤ ±2 nm

Absorbance Repeatability: ≤ 0.0005 AU

Measurement Time: ≤ 1 min

Data Interval: 1 nm

Dimensions: L: 265 mm / W: 340.5 mm / H: 262.3 mm

Weight: 9 kg

Display: 7-inch Touch Screen

Operating Temperature: 5–45°C

Storage Temperature: -20–60°C

Operating Humidity: < 75% RH

Light Source: Halogen-Tungsten Lamp

Power Supply: 24V / 3A

Power Consumption: 25 W

Operating System: Linux
