HUBER+SUHNER 87010023 Passive Antenna Railway Antenna 2G to 5G Cell WiFi

Gain: 4.5 dBi, 5.5 dBi, 6 dBi, 7.5 dBi, 7.5 dBi

VSWR: 2, 1.7, 1.7, 1.8, 2

Style: Sharkfin

Width: 85 mm

Height: 7 mm

Length: 145 mm

IP Rating: IP66

Impedance: 50 Ohms

Application: Railway

Unit Weight: 662.256 g

Cable Length: 0.23 m

Polarization: RHCP, Vertical

Mounting Style: Direct / Permanent Mount

Number of Bands: 5 Band

Center Frequency: 827 MHz, 1.335 GHz, 1.955 GHz, 2.45 GHz, 1.5754 GHz

Mechanical Style: Module

Maximum Frequency: 2.7 GHz

Minimum Frequency: 694 MHz

Termination Style: Connector

Antenna Connector Type: N Female, TNC Male

Protocol - GPS, GLONASS: GPS

Protocol - WiFi - 802.11: WiFi

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C

Protocol - Cellular, NBIoT, LTE: Cellular (NBIoT, LTE)
