Huazheng HZRZ-301B Transformer Winding Deformation Tester (100Hz ~ 2 MHz)

Working power supply: single phase AC 220V±10%, 50Hz（47~63 Hz）

Working temperature: -30℃~50℃ (Test host)

Working humidity: ≤90%RH, No condensation

Sweep range: 100Hz~2 MHz (Customizable 10MHz)

Frequency accuracy: 0.005%

Sweep mode: linear or logarithmic

Sweep interval: < 1 kHz

Measuring frequency range: -100dB~20dB

Sweep excitation output: 20Vpp

Detection accuracy: Better than ±0.5dB

Output impedance: 50Ω

Input port impedance: 1MΩ

Data storage format: Excel data format, can be opened in plain text
