Huazheng HPC601 Opacimeter (0～150℃)

Test Scope：No light transmission N:0～100% (equivalent to smoke value 0~10FSN)

Light absorption coefficient K:0～16.06 m-1

RPM：0～9990rpm Oil temp: 0～150℃

Indication error: ≤±2% ( measured value)

Stability: moment drift≤±1%/4H

Repeatability: ≤±1%

Resolution: N:0.1%, K:0.01m-1, RPM:10rpm, OIL TEMP:0.1℃

Output mode: digital direct reading, can be attached to the printer to print the smoke concentration (darkness) maximum value, test time, date. Can interface with computer networking

The measurement chamber temperature:

70℃ (automatic), when the temperature error of ≥± 10%, temperature and error indicator light

And-use temperature: -5~50°C, Relative humidity: ≤90%

Power: AC100~240V 50/60Hz or DC12V, Power consumption: 150VA

Dimensions (including bracket): 160(L)×400(W)×480(H)mm

Weight: 8kg
