Max. Load: 600 kN
Load accuracy: ≤1%
Load range: 2%-100% FS
Clamping method: Hydraulic clamping
Force resolution: 1/300000
Deformation indicating relative error: ≤ ±0.5%
Control range of stress rate: 1MP/S-60MP/S
Adjust range of test strain rate: 0.00025/S-0.0025/S
Control range of displacement rate: 0.5mm/min-50mm/min
Relative error of displacement indicating: ≤ ±1%
Disp. resolution: 0.01mm
Max. tension test space (mm): 650mm
Max. compression space(mm): 550mm
Clamping diameter of round sample (mm): Φ13-φ40mm
Clamping thickness of flat sample (mm): 0-30mm
Clamping width of flat smple(mm): 80mm
Diameter of upper and lower plate: φ180mm
Distance of bending roller: 30-580mm
Width of roller: 160mm
Max. piston stroke (mm): 250mm
Power supply: 380V, 50/60Hz, 3-Phase
