Maximum Energy(J): 2000
Minimum Energy(J): 300
Maximum Tup Mass(kg): 60
Tup Mass Accuracy: ±1%
Drop Height(mm): 750～3400
Velocity Of Drop(m/s): 3.8～7.6
Hammer Lifting Speed(m/min): 3
Height Resolution: 0.1
Height Accuracy(mm): ≤±10
Hardness Of Tup Nose: HRC58-62
Radius Of Tup Nose(mm): R25.4±2.5
Sample Centered Error(mm): ±1
Support Anvil Span: P-1、P-2、P-3
Specimen Dimension: P-1:(360±1)×(90±2)×(25±2.5)P-2:(130±1)×(50±1)×(20±1)P-3:(130±1)×(50±1)×(16±0.5)
Power Supply: 380v±10%,50/60Hz
