HST LAW-600H Computer Control Steel Strand Tension Testing Machine (600kN, AC380V)

Max.test force(kN): 600

Test machine class: 1 Class

Test force range（FS）: 2%-100%

Relative error of force reading(%): ≥±1

Test force resolution: 1/20000

Deformation measurement range (FS): 2%～100%

Deformation resolution: 1/20000

Relative error of deformation reading (%): ≥±0.5

Displacement resolution (mm): 0.01

Relative error of displacement reading (%): ≥±0.5%

Effective column space (mm): 600

Tension fixtures configuration: Hydraulic automatic clamping type

Stranded wire clamping range(mm): Ф12.7 or Ф15.2 or Ф15.2 mm

Power supply: 380V/50Hz/Three-phase four-wire system

Compression grip: Φ160 sphere automatically leveling compression grip

>> Optional parts

Bending grip: Compression platen, Three points bending grip

Bending roller upper and lower diameter:

Power supply: 3-phase,AC380V, 50Hz（can be customized）
