HST HVS-1000 Micro Vicker Hardness Tester

Display model: Big LCD Digital Display

Hardness values: Direct display

Exchange scales: HRA, HRB, HRC, HRD, HRF, HV, HK, HBW, HR15N, HR30N, HR45N, HR15T, HR30T, HR45T

Test force: 10gf (0.098N), 25gf (0.245N), 50gf (0.49N), 100gf (0.98N), 200gf (1.96N), 300gf (2.94N), 500gf(4.9N), 1kgf (9.8N)

Turret type: Manual

Loading and unloading mode: Automatic

Dwell Time (Adjustable): 0 to 60 seconds

Micrometer eyepiece multiple: 10X(optional 15X)

Me measurement resolution: 0.25µm (drum reading)

Objective magnification: 10X 40X

Total magnification: 100X (objective) 400X(measurement)

Measurement range: 150µm

Light source: Halogen lamp (brightness adjustable)

Hardness conversion: Brinell, rockwell, surface rockwell

Max. height of specimen: 80mm

Depth at center line: 95mm

XY test table size: 100X100mm Max. movement: 25*25mm

Min. measuring unit: 0.01μm

RS232,Built-in print,data statistics: Yes
