Hopetech HT3544-12H Multi-Channel Resistance Tester (3mΩ~3MΩ)

Channel No.: 12-channel

Display: 3.5 inch  TFT-LCD display

Measurement items: ESR, temperature

Basic accuracy: 0.1%±10 reading (3mΩ,30mΩ,3MΩ); 0.05%±4 readings;0.02%±2 readings(the other ranges)

Measurement range : 3mΩ/30mΩ/300mΩ/3Ω/30Ω/300Ω/3kΩ/30kΩ/300kΩ/3MΩ

Measurement speed: FAST(50Hz:21ms, 60Hz:18ms), SLOW(200ms)

Maximum test current: DC 1A, Max:5.5V

Temperature: Range:-10°C ~60°C Accuracy:±1°C

Correction: Short-circuit reset for all ranges

Comparator: HIGN/IN/LOW  sorting,10 bin-out

Internal data storage: Support with PC software and store in PC

Trigger: Internal/external/manual trigger

Signal source: AC 1kHz, Test current: <150mA

Resolution: 0.1μΩ

Other functions:  temperature correction, power frequency setting

Interface: External I/O,LAN,RS232

Power supply: Voltage: 100VAC～256VAC; Frequency: 50Hz～60Hz;

Rated Power: 10W

Dimensions: 325 mm (L) x215mm (W) x 96.5mm (D),without sleeve

Accessory : Standard:HT9363A,HT9348,power cord

Weight: 2kg
