Actuator: Paddle
Illuminated: Non-Illuminated
Unit Weight: 61.230 g
Bushing Size: 15/32-32
Contact Form: DPDT
Mounting Type: Bushing
Terminal Seal: Sealed
Actuator Style: Standard Round
Current Rating: 100 mA
Mounting Style: Panel Mount
Actuator Length: 17.27 mm
Contact Plating: Nickel
Termination Style: Wire Lead
Voltage Rating AC: 115 VAC
Voltage Rating DC: 28 VDC
Maximum Operating Temperature: + 71 C
Minimum Operating Temperature: - 65 C
