Honestco TPD26A RF Probe (26GHz, SMA (J))
ManufacturerHonestco(View more products from this manufacturer)
ModelTPD26A
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Characteristic impedance: 50 ohm
Frequency range: DC to 26.5GHz
Insertion loss (Typ. GSGSG-150μm): -0.8dB
Return Loss (Typ. GSGSG-150μm): -18dB
DC voltage: 100V
DC current: 1A
RF Power @ 10GHz max: 5W
Contact resistance on Au: 0.05 ohm
Connector: SMA (J)
Available Pitch: 50 to 1000μm (25um step)
Available Configuration: GSSG, GSGSG
Probe Material: Nickel Alloy
Body Material: Aluminum Alloy
XY position error: Max 10um
Planarity error: Max 10um
