Honestco 4Y0CQ0CP0360 Cable Assemblies (40GHz)
ManufacturerHonestco(View more products from this manufacturer)
Model4Y0CQ0CP0360
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Maximum Operating Frequency: 40GHz
Length: 36 I
Impedance: 50 Ohms
Dielectric Constant (nominal): 1.4
Velocity of Propagation: 0.85
Temperature: -55 to 125°C
Nominal Outer Diameter: 0.150 inch (3.8mm)
Minimum Bend Radius (multiple bends): 1 inch (25.4mm)
Nominal Weight: 11g/ft (36 g/m)
Typical Insertion Loss at 40 GHz: -2.65 dB
Guaranteed Insertion Loss at 40 GHz: -2.96 dB
Guaranteed VSWR at 40 GHz: 1.35:1
Guaranteed Return Loss at 40 GHz: -16.53 dB
