Rated voltage: 250V; 500V; 1000V; 2500V; 5000V
Measuring Range:
250V: 0.1～100.0MΩ
500V: 0.1～99.9MΩ; 80～1000MΩ
1000V: 0.1～99.9MΩ; 80～999MΩ; 0.80～2.00GΩ
2500V: 0.1～99.9MΩ; 80～999MΩ; 0.80～9.99GΩ; 8.0～100.0GΩ
5000V: 0.1～99.9MΩ; 80～999MΩ; 0.80～9.99GΩ; 8.0～99.9GΩ; 80～20000GΩ
Display range:
250V: 0.1~100.0 MΩ
500V: 0.1~1000 MΩ
1000V: 0.1M~2.00 GΩ
2500V: 0.1M~100.0 GΩ
5000V: 0.1M~2000 GΩ
Open circuit Voltage:
DC250V; +10% ,-10%
DC 500V; + 20%,-10%
DC 1000V; + 20%,-0%
DC 2500V; +20%,-0%
DC5000V; +20%,-0%
Rated Current
1MΩ load: 1mA~1.2mA (1000V)
2.5MΩ load: 1mA~1.2mA (2500V)
5MΩ load: 1mA~1.2mA (5000V)
Short-circuit Current: 5mA±0.5mA
Accuracy:
±5%±3dgt (250V; 500V, 1000V, 2500V)
±5%±3dgt±20% (5000V)
