- Rated input current: 500A AC/DC
- Max. allowable input: 700 Arms (1000 Apeak, requires derating at frequency)
- Frequency characteristics: Amplitude: DC to 100 kHz
- Phase: DC to 100 kHz
- Amplitude and Phase accuracy: DC, 45 Hz ≤ f ≤ 66 Hz
(±0.05 % rdg. ±0.01 % f.s. (Phase: ±0.2 deg) Defined to 100 kHz
- Power consumption: 5 VA max. (at 500 A/55 Hz, ±12 V power requirement)
- Output voltage rate: 2 V /rated current value (voltage output with the Sensor Unit 9555-10, use with a device having a 1 MΩ input resistance or higher)
- Max. rated voltage to earth: AC/DC 1000 V (50/60 Hz, CAT III )
- Core diameter: φ 36 mm (1.42 in)
- Operating temperature, humidity: 0°C to +50°C (32°F to 122°F)
80% rh or less (with no condensation)
- Power supply : DC ±11 V to ±15 V (Power suppled via the 9555-10, which supports 100 to 240 V AC)
- Dimensions and mass: 160 mm (6.30 in)W × 112 mm (4.41 in)H × 50 mm (1.97 in)D, 850 g (30.0 oz), cord length: 3 m (9.84 ft)
- Accessories: Instruction manual ×1, Mark bands ×6
