Basic functions: AC 4-terminal method resistance measurement
Display : Fluorescent tube (digital display)
Current setting range : 3.0 A to 31.0 A AC (0.1 A resolution), into 0.1Ω load
Max. output power : 130 VA (at output terminals)
Open-terminal voltage : Max. 6 V AC
Generator frequency : 50 Hz or 60 Hz sine wave (selectable)
Resistance measurement : 0 to 1.800 Ω (0.001 Ω resolution), Accuracy: ±2% rdg. ±4 dgt. after zero-adjust
Voltage measurement : 0 to 6.00 V AC (single range 0.01 V resolution), Accuracy: (1 % rdg. +5 dgt.)
Monitor section: 0 to 35.0 A AC/ 0 to 6 V AC, Refresh rate: 2 times/s
Timer display : Counts down time after start until preset time, Shows elapsed time after start
Timer setting : 0.5 s to 999 s
Comparator : PASS/FAIL evaluation using preset upper/lower limit, buzzer sound, signal output
Memory function: Max. 20 settings (with save/load)
Interfaces : EXT I/O, EXT SW, GP-IB or RS-232C (option)
Power supply : 240 V AC (switching, 50/60 Hz)
Dimensions and mass : 320 mm (12.60 in)W × 90 mm (3.54 in)H × 263 mm (10.35 in)D, 7 kg (246.9 oz)
Accessories : Power cord ×1, Instruction Manual ×1, Spare fuse (inlet) ×1, Shorting bar ×2
