HINOTEK XSZ-107 Biological Microscope (4X,10X,40X(S),100X(S,Oil))

Viewing Head: Trinocular Head for Video Camera (C Mount) (CCD is option)

Objective: Achromatic DIN 4X,10X,40X(S),100X(S,Oil)

Eyepiece: Wide Field Eyepiece WF10X; Wide Field Eyepiece WF16X (option)

Stage: Double Layers Mechanical Stage140*140mm Moving range 45*75mm

Focusing: Coaxial Coarse And Fine Adjustment, Focusing Range 30mm, Fousing Interval 0.002mm

Condenser: Abbe N.A 1.25 with lris Diaphragm & Filter

Illumination: Built-in Illumination, Halogen Lamp 110V/220V/6V 20W

Package: Foam + Carton packing (Standard Packing); Foam + Wooden Case + Caron packing (Optional Packing)
