HINOTEK WYV-S Digital Refractometer (0-100%, 1.30000-1.70000, 1.30000-1.95000)

Measurement:

Refractive index ND: 1.30000-1.70000 (liquid)

Refractive index ND: 1.30000-1.95000 (solid)

Brix: 0-100%

Accuracy:

Refractive index ND: ± 5 x 10-5

Brix: 0.01 %

Measuring Resolution:

Refractive index ND: 1 x 10-6

Brix: 0.01 %

Wavelengths: 706.5nm, 656.3nm, 589.3nm, 587.6nm, 546.1nm, 486.1nm, 435.8nm, 404.7nm

Light Source: Hydrogen lamp/ Sodium lamp/ Helium lamp

Temperature Display Range: 0-50°C

Magnification of the telescope objectives: 5x

Display: 5.6 inch color touch screen

Interface: RS232/USB/U disk

Weight (Gross): 80kg

Overall dimensions: 720mm x 550mm x 550mm
